Máy nén trục vít nước biến tần Fusheng SWV Series

Name: Máy nén trục vít nước biến tần Fusheng SWV Series
SKU: Fusheng SWV Series
Availability: InStock

Mã sản phẩm: Fusheng SWV Series

Liên hệ(Giá đã bao gồm 10% VAT)

Thương hiệu:

Nhóm sản phẩm: Máy nén khí

Đơn vị tính

Bảo hành

Xuất xứ

Đăng ký nhận báo giá miễn phí

CHAT ZALO Giải đáp hỗ trợ tức thì GỌI NGAY

Thông tin chi tiết
Liên Hệ

Thông số kỹ thuật của máy nén trục vít nước biến tần Fusheng SWV Series

Model	Áp suất làm việc (kg/c㎡G)	Lưu lượng (m³/phút)	Công suất HP(kW)	Điện áp (V)	Trọng lượng (kg)	Kích thước (mm)
SWV15A	7	2.2	20 (15)	220/380/440	970	1900x1100x1750
SWV15A	8	2.1	20 (15)	220/380/440	970	1900x1100x1750
SWV15A	9	2	20 (15)	220/380/440	970	1900x1100x1750
SWV22A	7	3.4	30 (22)	220/380/440	1000	1900x1100x1750
SWV22A	8	3.1	30 (22)	220/380/440	1000	1900x1100x1750
SWV22A	9	3	30 (22)	220/380/440	1000	1900x1100x1750
SWV30A	7	4.7	40 (30)	220/380/440	1370	2100x1200x1850
SWV30A	8	4.4	40 (30)	220/380/440	1370	2100x1200x1850
SWV30A	9	4.3	40 (30)	220/380/440	1370	2100x1200x1850
SWV37A	7	5.8	50 (37)	220/380/440	1400	2100x1200x1850
SWV37A	8	5.3	50 (37)	220/380/440	1400	2100x1200x1850
SWV37A	9	5	50 (37)	220/380/440	1400	2100x1200x1850
SWV30W	7	1.4	30 (40)	220/380/440	1170	2100x1200x1400
SWV30W	8	4.4	30 (40)	220/380/440	1170	2100x1200x1400
SWV30W	9	4.3	30 (40)	220/380/440	1170	2100x1200x1400
SWV37W	7	5.8	50 (37)	220/380/440	1200	2100x1200x1400
SWV37W	8	5.3	50 (37)	220/380/440	1200	2100x1200x1400
SWV37W	9	5	50 (37)	220/380/440	1200	2100x1200x1400
SWV55W	7	9.5	75(55)	220/380/440	1700	2500x1400x1500
SWV55W	8	8.8	75(55)	220/380/440	1700	2500x1400x1500
SWV55W	9	8.1	75(55)	220/380/440	1700	2500x1400x1500
SWV75W	7	12.3	100(75)	220/380/440	1850	2500x1400x1500
SWV75W	8	11.8	100(75)	220/380/440	1850	2500x1400x1500
SWV75W	9	11.3	100(75)	220/380/440	1850	2500x1400x1500
SWV90W	7	12.3	120(90)	220/380/440	2900	3200x1500x1700
SWV90W	8	11.8	120(90)	220/380/440	2900	3200x1500x1700
SWV90W	9	11.3	120(90)	220/380/440	2900	3200x1500x1700
SWV120W	7	19.7	160(120)	220/380/440	3000	3200x1500x1700
SWV120W	8	19.2	160(120)	220/380/440	3000	3200x1500x1700
SWV120W	9	17.5	160(120)	220/380/440	3000	3200x1500x1700
